Multi-region

Regions represent geographic or logical deployment zones. Each region can have its own database URL, control plane URL, and lifecycle status. Tenants can be migrated between regions to satisfy compliance requirements or optimize latency.

Region model

interface Region {
  id: string;
  display_name: string;       // "EU West (Frankfurt)"
  slug: string;               // "eu_west"
  control_plane_url: string;  // "https://eu.stratum.example.com" (http or https, without credentials)
  database_url: string;       // stored but never exposed in API responses
  is_primary: boolean;
  status: "active" | "draining" | "inactive";
  metadata: Record<string, unknown>;
}

Region lifecycle

active  ──>  draining  ──>  inactive

Status	Description
active	Accepting new tenants, serving traffic
draining	No new tenants, existing tenants being migrated out
inactive	Empty, can be safely deleted

Creating regions

const eu = await stratum.createRegion({
  display_name: "EU West (Frankfurt)",
  slug: "eu_west",
  control_plane_url: "https://eu.stratum.example.com",
  is_primary: false,
  metadata: { provider: "aws", az: "eu-west-1" },
});

const us = await stratum.createRegion({
  display_name: "US East (Virginia)",
  slug: "us_east",
  is_primary: true,
});

Via the API:

curl -X POST http://localhost:3001/api/v1/regions \
  -H "X-API-Key: YOUR_ADMIN_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "display_name": "EU West (Frankfurt)",
    "slug": "eu_west",
    "control_plane_url": "https://eu.stratum.example.com",
    "is_primary": false,
    "metadata": {"provider": "aws", "az": "eu-west-1"}
  }'

Migrating tenants

Move a tenant to a different region:

await stratum.migrateRegion("tenant-uuid", eu.id);

Via the API:

curl -X POST http://localhost:3001/api/v1/tenants/TENANT_UUID/migrate-region \
  -H "X-API-Key: YOUR_ADMIN_KEY" \
  -H "Content-Type: application/json" \
  -d '{"region_id": "EU_REGION_UUID"}'

Migration validations

The migration checks:

• Tenant exists and is not archived
• Target region exists
• Target region status is active (not draining or inactive)

If the target region is not active, the migration throws RegionNotActiveError. The control plane answers 409 with the code REGION_NOT_ACTIVE.

Managing regions

List

curl http://localhost:3001/api/v1/regions \
  -H "X-API-Key: YOUR_KEY"

Update status

Drain a region before decommissioning:

curl -X PATCH http://localhost:3001/api/v1/regions/REGION_UUID \
  -H "X-API-Key: YOUR_ADMIN_KEY" \
  -H "Content-Type: application/json" \
  -d '{"status": "draining"}'

Delete

If active tenants are still assigned to the region, the deletion fails with RegionInUseError. The control plane answers 409 with the code REGION_IN_USE:

curl -X DELETE http://localhost:3001/api/v1/regions/REGION_UUID \
  -H "X-API-Key: YOUR_ADMIN_KEY"

Data residency example

For GDPR data residency compliance, create regions per jurisdiction and assign tenants accordingly:

// Create jurisdiction-specific regions
const eu = await stratum.createRegion({
  display_name: "EU (Frankfurt)",
  slug: "eu_frankfurt",
});

const us = await stratum.createRegion({
  display_name: "US East (Virginia)",
  slug: "us_east",
  is_primary: true,
});

// EU customer data stays in EU
await stratum.migrateRegion("eu-tenant-uuid", eu.id);

// US customer data stays in US
await stratum.migrateRegion("us-tenant-uuid", us.id);

Tip

Combine multi-region with config locking to enforce data residency:

await stratum.setConfig(euTenantId, "data_region", {
  value: "eu-west-1",
  locked: true, // no descendant can change this
});

Region slug rules

Region slugs follow the same rules as tenant slugs:

• Lowercase letters, digits, and underscores only
• Must start with a letter
• Maximum 63 characters
• Pattern: ^[a-z][a-z0-9_]{0,62}$

Authorization

Route	Required Scope
GET /api/v1/regions	read
POST /api/v1/regions	write
PATCH /api/v1/regions/:id	write
DELETE /api/v1/regions/:id	write
POST /api/v1/tenants/:id/migrate-region	admin

Security

The database_url field is stored internally but never exposed in API responses. This prevents accidental leakage of database credentials through the API.
